Sector experience Food / beverage
Media experience Wastewater / effluent
Services provided Design
Construction
Installation
Commissioning
Client Konya Seker
Year completed 2004



Konya Seker is the largest private sugar producer in Turkey and has invested strongly in modern production facilities in recent years. In 2004 they commissioned a new beet sugar factory in Cumra, a small town in central Anatolia. The factory can process up to 12.000 tons of sugar beet per day and produces up to 1,500 tons of sugar per day (during the sugar season).

In order to treat the wastewater from the beet sugar factory, a wastewater treatment plant (WWTP) had to be constructed.

Konya Seker awarded the contract for the WWTP to H+E because of their extensive experience with wastewater treatment for the sugar industry (14 anaerobic plants built over recent years in Europe and the Near East).

The plant is designed to treat the two wastewater flows that typically originate from beet sugar production. One is a highly polluted wastewater flow from beet washing (flow rate 3,600 m³/d), the second a slightly polluted condensate flow from sugar crystallisation (flow rate 5,520 m³/d).

The highly polluted wastewater from beet washing is treated in an anaerobic stage consisting of a hydrolysis reactor and an anaerobic contact sludge reactor ANAFIT-CS with biogas injection system.

The ANAFIT-CS reactor, which was developed by SH+E is particularly suited to wastewater with a high calcium concentration, such as beet washing water. It operates reliably and dependably avoids operation problems which, in processes of this kind, can be caused by calcium carbonate clogging. Furthermore, it achieves a constant COD removal of more than 95%.

The effluent of the anaerobic stage is treated together with the slightly polluted wastewater in the aerobic stage, which is designed as a nitrifying activated sludge tank (equipped with the non-clogging aeration system AEROFIT-D) and an upstream denitrification stage. Remaining organic pollution and nitrogen is eliminated in this stage.

In 2007, a bio-ethanol plant was added to the sugar factory and the wastewater treatment plant was upgraded by H+E to cater for the additional wastewater.

The WWTP works very well and achieves discharge values lower than EU law requires: (COD < 60 mg/l, BOD5 < 30 mg/l, N < 30 mg/l).

The contract for the new WWTP, signed in April 2004, was developed to a strict schedule. Construction began in August 2004 and the commissioning in December 2004. The entire project was completed in less than a year.

Due to the success of this project, Konya Seker later commissioned a WWTP for their sugar production in Konya.

References are available on request and we will happily arrnage for you to visit a working plant if you wish.


Konya Seker is the largest private sugar producer in Turkey and has invested strongly in modern production facilities in recent years. In 2004 they commissioned a new beet sugar factory in Cumra, a small town in central Anatolia. The factory can process up to 12.000 tons of sugar beet per day and produces up to 1,500 tons of sugar per day (during the sugar season).

In order to treat the wastewater from the beet sugar factory, a wastewater treatment plant (WWTP) had to be constructed.

Konya Seker awarded the contract for the WWTP to H+E because of their extensive experience with wastewater treatment for the sugar industry (14 anaerobic plants built over recent years in Europe and the Near East).

The plant is designed to treat the two wastewater flows that typically originate from beet sugar production. One is a highly polluted wastewater flow from beet washing (flow rate 3,600 m³/d), the second a slightly polluted condensate flow from sugar crystallisation (flow rate 5,520 m³/d).

The highly polluted wastewater from beet washing is treated in an anaerobic stage consisting of a hydrolysis reactor and an anaerobic contact sludge reactor ANAFIT-CS with biogas injection system.

The ANAFIT-CS reactor, which was developed by SH+E is particularly suited to wastewater with a high calcium concentration, such as beet washing water. It operates reliably and dependably avoids operation problems which, in processes of this kind, can be caused by calcium carbonate clogging. Furthermore, it achieves a constant COD removal of more than 95%.

The effluent of the anaerobic stage is treated together with the slightly polluted wastewater in the aerobic stage, which is designed as a nitrifying activated sludge tank (equipped with the non-clogging aeration system AEROFIT-D) and an upstream denitrification stage. Remaining organic pollution and nitrogen is eliminated in this stage.

In 2007, a bio-ethanol plant was added to the sugar factory and the wastewater treatment plant was upgraded by H+E to cater for the additional wastewater.

The WWTP works very well and achieves discharge values lower than EU law requires: (COD < 60 mg/l, BOD5 < 30 mg/l, N < 30 mg/l).

The contract for the new WWTP, signed in April 2004, was developed to a strict schedule. Construction began in August 2004 and the commissioning in December 2004. The entire project was completed in less than a year.

Due to the success of this project, Konya Seker later commissioned a WWTP for their sugar production in Konya.

References are available on request and we will happily arrnage for you to visit a working plant if you wish.
