Specification

Speed: Range is 10 - 30 strokes per minute

Division: The division box is six-pocket, giving a weight range of 300 – 1,100 g, dependent on dough density

Frames: The Divider’s painted steel side frames support the stainless steel top box

Covers and Guards: All exterior covers are stainless steel with operator access covers hinged for easy cleaning and maintenance. The hinged covers are fully interlocked for safety

Mobility: Mounted on wheels for mobility

Drive Components: A 4 kW geared motor directly drives a camshaft that operates the stainless steel division box, nickel cast iron knife and nylon dies.

The nickel cast iron ram is driven by a separate 3.2 kW servo drive motor. The ram pressure can be adjusted to suit individual products for minimum dough damage.

Oil Systems: A positive displacement mechanical pump distributes oil to lubricate the sliding surfaces

An oil tank is included that may either be filled manually, or automatically from a bulk oil system. A low level sensor will stop the Divider to prevent it running without oil

Weight Control: The weight control mechanism is motorized and may be linked to feedback from a Checkweigher
