ELIQUO HYDROK - flushing systems

The Eliquo Hydrok CWF Storm Flush™ , also called a 'Flushing Bell', storm tank cleansing system provides a cost effective removes sedimentation by the use of automatic, self-regulated flushing technology.

It is a highly effective non-powered cleaning system that can be used on all stormwater retention tanks utilising the sewage stormwater for the flushing process thus requiring no additional fresh water.

Operating principle

CWF Storm Flush™ is a simple method for sediment removal. Stormwater is held in reserve in the storage reservoir, filled during the tank filling process. At the end of a storm event and after the system has emptied, the retained flushing water is released via the vacuum break within the flushing vessel. This creates a RFP (Roughing, Fine and Polishing) staged flushing regime which mixes and carries the sediment from the base of the tank to the receiving sump.

Benefits

Cleans ecologically, without external power, external water supply and controls
Flushes even after partial fillings
Fully self priming and flushing operation
Suitable for new tank and existing tank retrofit
Suitable for both open and below ground installations
No moving parts
Intrinsically safe
Any shape tank
Utilises stormwater for the flushing process
Retains total volume of storm tank
Final flush polishing stage utilises settled stormwater
Synchronised flushing of multi unit installations within larger tanks
