The PCE-IR 80 infrared thermometer is used to quickly control the temperature of food in canteen kitchens, catering services, refrigerated warehouses and warehouses.

Types of measurement

1. Non-contact

It can measure the temperature of the object without contact via infrared: the measuring range is -35 ... 330°C / -31 ... 626°F. The emissivity of the infrared thermometer is adjustable, so that the best measuring results can always be achieved.

2. Contact

Alternatively, it has a stainless steel needle sensor so that the meter can also be used as a puncture, infrared thermometer. If the core temperature is measured by this method, the infrared thermometer can measure in the range between -20 ... 260°C / -4 ... 500°F. The unit of the penetration thermometer can be switched between °C and °F. The fast response time of 10ms and high resolution of 0.1°C / 1.8°F complete the scope of the infrared thermometer.

Key features

  • Non-contact and contacting temperature measurement combined in one device

  • Large measuring range

  • Suitable for use in the food industry according to HACCP

  • Emissivity adjustable (pre-set for food)

  • Low response time

  • Measurement hold function (min / max)

  • Continuous measurement function

  • Waterproof, enabling simple and hygienic cleaning (flushable housing)

  • Supplied with a CR2032 battery

Technical specification

Measurement type: infrared

  • Measuring range: -35 ... 330°C / -31 ... 626°F

  • Resolution: 0.1°C / 0.18°F

  • Accuracy:
    -35 ... 0°C / -31 ... 32°F
    ± 4°C / 7.2°F > 0°C / 32°F
    ± 2% of rdg. ± 2°C / 3.6°F

Measurement type: penetration sensor

  • Measuring range: -20 ... 260°C / -4 ... 500°F

  • Resolution: 0.1°C / 0.18°F

  • Accuracy: ± 1% of rdg. ± 1.5°C / 2.7°F

  • Optical resolution: 4: 1

  • Emissivity adjustable: 0.1 ... 1.0

  • Response time: 10ms

  • Spectral: 8 ... 14 µm

  • Power supply: 3.0V CR2032 battery

  • Operating conditions: 0 ... 50°C / 32 ... 122°F; max 80% rh

  • Weight: approx 100g / < 1lb

  • Dimensions: 151 x 41 x 20mm | 6 x 1.6 x 0.8"
