The OxiAir HD diffused lake aerator is designed and developed with depth in mind and can aerate lakes up to 10m+ deep.

The super-silent bankside compressor pumps air through the diffuser membranes situated on the lake bed. This air travels up through the water column and breaks through the thermocline, reducing the effects of thermal stratification. Diffused aeration mixes the water column efficiently and increases the dissolved oxygen levels within a lake. At a depth of 2m, each diffuser circulates an approximate volume of 11,065 litres of water per minute.

Features

  • Designed and manufactured in the UK

  • Simple plug-and-play operation

  • Operates in deeper water

  • Very low operating costs

  • No electrical components required in the water body

  • Very reliable, virtually silent and low maintenance

  • Manifolds constructed of brass and stainless for winter operation (most competitors' units are plastic)

  • No loud water movement or splashing

  • Extremely hardwearing

  • Brass check valves

  • Self-cleaning diffusers

  • Self-weighted air tubing

  • 500mm diffuser tube length

  • Disc style diffusers are available

  • Optional enclosure colours are available

  • 2-year warranty on pump

  • 15-year warranty on weighted hose

  • 5-year warranty on diffusers

  • Lifetime warranty on the enclosure

  • Large bespoke units available

  • Free no-obligation quote

Model specifications

Aeration System

Diffuser Quantity

Pump Quantity

Approx. Circulation Rate @ 2m Depth Combined. (per minute)

Max LPM Air Output

Wattage

OxiAir HD 2

2

1

22m3

117

370W

OxiAir HD 3

3

1

33m3

117

370W

OxiAir HD 4

4

1

44m3

117

370W

OxiAir HD 5

5

2

55m3

234

740W

OxiAir HD 6

6

2

66m3

234

740W

OxiAir HD 7

7

2

77m3

234

740W

OxiAir HD 8

8

2

88m3

234

740W

OxiAir HD 9

9

3

99m3

351

1.11KW

OxiAir HD 10

10

3

110m3

351

1.11KW

OxiAir HD 11

11

3

121m3

351

1.11KW

OxiAir HD 12

12

3

132m3

351

1.11KW

OxiAir HD 13

13

3

143m3

351

1.11KW

OxiAir HD 14

14

4

154m3

468

1.48KW

OxiAir HD 15

15

4

165m3

468

1.48KW

OxiAir HD 16

16

4

176m3

468

1.48KW

OxiAir HD 17

17

4

187m3

468

1.48KW

OxiAir HD Diffused Lake Aerator Approx. Surface Area

Aeration System

1m - 4m Depth

4m-10m+ Depth

OxiAir HD 2

1 Acre

2 Acres

OxiAir HD 3

1.5 Acres

3 Acres

OxiAir HD 4

2 Acres

4 Acres

OxiAir HD 5

2.5 Acres

5 Acres

OxiAir HD 6

3 Acres

6 Acres

OxiAir HD 7

3.5 Acres

7 Acres

OxiAir HD 8

4 Acres

8 Acres

OxiAir HD 9

4.5 Acres

9 Acres

OxiAir HD 10

5 Acres

10 Acres

OxiAir HD 11

5.5 Acres

11 Acres

OxiAir HD 12

6 Acres

12 Acres

OxiAir HD 13

6.5 Acres

13 Acres

OxiAir HD 14

7 Acres

14 Acres

OxiAir HD 15

7.5 Acres

15 Acres

OxiAir HD 16

8 Acres

16 Acres

OxiAir HD 17

8.5 Acres

17 Acres

Installation

Heathland Group offers a full installation service for all of its aeration equipment, including:

  • Full cabling

  • Trenching

  • Control panel installation

  • Control panel set-up

  • Aerator installation

Maintenance

Heathland Group has its own in-house fully-equipped servicing centre for any general maintenance, servicing or repair of aerators, and can also supply onsite support and maintenance should returning the item not be possible. (During the 2-year labour warranty period a charge will be made for a site callout but all onsite time will be completed free of charge.)

Heathland can supply aeration equipment and installation services to domestic and commercial clients in the UK and throughout Europe.
