HEAT-FIT™ is a fire retardant system made for lightweight, corrosion-free thermoplastic piping in marine settings, allowing use in essential onboard applications where fire resistance is required.

  • Fire protection system for thermoplastic marine piping
  • On average 30% lighter than metal alternatives
  • Compatible with PE100 ecoFIT piping systems
  • Tested to IMO Resolution A753 Fire Resistance L3
  • Protects pipes and fittings at 1000°C for up to 30 minutes under 3 bar pressure
  • Manual installation with no hot work or specialist skills needed
  • Approved by ABS, BV, DNV, LR, and RINA

Applications

  • Cruise ships
  • Merchant fleets
  • Offshore platforms
  • Floating wind farms
  • Essential onboard piping systems

Materials

Co-extruded PE pipes with halogen-free intumescent coating

Glass fibre fabric jackets with halogen-free intumescent coating and thermoplastic urethane lamination

Performance

Fire resistance at 1000°C for 30 minutes under 3 bar pressure

Meets IMO fire resistance requirements for essential applications

Installation

Buttfusion or electrofusion jointing for pipes

Manual installation for jackets

No hot work or specialist skills required

Welds are trackable and recordable

Product accreditations

Approved by ABS, BV, DNV, LR, RINA
