Media Water
Valve type Gate / knife valves
Construction Titanium
Min. connection size (mm) 15
Max. connection size (mm) 1400



Blackhall titanium and exotic alloy gate valves Series 4100 are designed for marine applications.

They feature an outside-screw rising stem, a non-rising handwheel, a bolted bonnet, a bolted gland and a solid wedge.

Technical data
• Flanges to ANSI B 16.5 and BS 1560 raised face.
• Valve design and shell wall thickness in accordance to ANSI B. 16.34.
• Face to face in accordance with ANSI B. 16.10.

Options
• Renewable soft seat.
• Renewable body seats.
• Gearbox operation recommended for valves 16" (DN 400 and above).
• Hydraulic, electric and pneumatic actuator options.
• Live loaded glands.
• Flanges and end connections: butt weld, socket weld and screwed.
• Materials to customer specification.
• Larger valves from 24" (DN 600) up to 56" (DN 1400) on application.


Blackhall titanium and exotic alloy gate valves Series 4100 are designed for marine applications.

They feature an outside-screw rising stem, a non-rising handwheel, a bolted bonnet, a bolted gland and a solid wedge.

Technical data
• Flanges to ANSI B 16.5 and BS 1560 raised face.
• Valve design and shell wall thickness in accordance to ANSI B. 16.34.
• Face to face in accordance with ANSI B. 16.10.

Options
• Renewable soft seat.
• Renewable body seats.
• Gearbox operation recommended for valves 16" (DN 400 and above).
• Hydraulic, electric and pneumatic actuator options.
• Live loaded glands.
• Flanges and end connections: butt weld, socket weld and screwed.
• Materials to customer specification.
• Larger valves from 24" (DN 600) up to 56" (DN 1400) on application.
