The MAS screw press filter is ideal for dehydrating and separating all kinds of solid or liquid process liquids, waste and residue flows.

The internal screw transports the product from the inlet to the delivery chamber.

As the back-pressure in the delivery chamber can be accurately adjusted, the quality of the end product (both effluent and dry mass) can be easily regulated. For instance, a number of applications require the effluent to be very clean, whereas the main criterion in other applications is the proportion of dry matter.

Since the counter-pressure is adjustable and self-correcting, the MAS screw press filter can be used for other applications as well.

The machine operates at a standard low speed of 24rpm, and therefore is very quiet. Other speeds are possible at customer request.

Technical data

  • Low standard power consumption (2.2 kW)

  • Capacity up to 100 m³ per hour, depending on the product being processed

  • Filter mesh size: 100 to 1000 µm

  • Dimensions: 2417x405x550 mm

  • No pressure build-up within the filter

  • Machine housing: cast iron or corrosion-proof material

Range:

  • SP280 - The SP280 is used on higher pressure applications 3 - 8 bar

  • SP300
