Did you know that landfill permits often require that gas levels are monitored and reported on? Or that gas monitoring often forms part of phase II site investigations or planning conditions?

Innovative ground gas monitoring techniques and innovations are essential in not only allowing you to cross the t's and dot the i's but to also allow you to carry out your work in the most efficient and cost effective way as possible.

The newest and most cost effective way of monitoring ground gas comes in the form of the GasClam, the FIRST and ONLY high frequency ground gas monitor that incorporates VOC (Volatile Organic Compound) monitoring and ground water level data and is available at Shawcity to hire for only £250 p/w!

What is this latest innovation and why can it save you money?

The GasClam, manufactured by IonScience, is an in-situ ground gas monitor that has an intrinsically safe Modem option for uploading real time data to web access on a daily basis or can be interrogated from its own USB port on site. The traditional methodology for ground gas monitoring has been ‘spot monitoring’ – taking event readings at various set times to predict the sub surface gas regime on both on Brownfield and Landfill sites. Advancements in technology have now improved on this method allowing for the monitoring of gas concentrations over time in both the pre and post development of these sites.

GasClam can be installed in an existing or new borehole on a site and left to continuously monitor gas levels over several months and can monitor Methane (CH4), Carbon Dioxide (CO2), Oxygen (O2), Borehole Pressure (Barometric) and Atmospheric Pressure for use on conventional risk sites; such as ex-landfills. However there are also options to include Hydrogen Sulphide (H2S), Carbon Monoxide (CO), Volatile Organic Compounds (VOCs); using Photo Ionisation Detector (PID) technology and even a water level transducer to measure water table movement. This allows the user to monitor all of these parameters in one unit and most importantly at regular intervals, usually once an hour, over a specific monitoring period.

Monitoring over regular intervals opposed to using traditional methods now means that you are able to speed up the site development allowing you to collect robust and accurate data in as little as 3 months rather than 2 years. This means that you are not only achieving the best quality data but that you are reducing the time it takes to collect the data as well as reducing the costs of buying or hiring monitoring equipment over extended periods of time.

How do we know it works?

As with any new piece of technology, the GasClam has undergone scrutinous testing and users have reported their approval of the technology. GasClam has already been used by a number of large companies accross the UK including Cuadrilla who commissioned GasClam to monitor background gas concentrations prior to operations, as well as to record and transmit gas concentrations throughout operations.

How else can it save you money?

The GasClam boasts a variety of advantages over traditional spot monitoring methods, however this does not mean it will have any effect on your budget, in fact with the hire solution that Shawcity offers, it means that this has now undoubtedly become the most cost effective way to use the instrument. To hire the GasClam for one week will cost £250. Shawcity can provide training ensuring that you get the most out of the hire.
