Product name Proline Promass F 100
Media Gases
Process liquids
Flowmeter type Coriolis flowmeters
Characteristics Clamp on
Accuracy (±%) ±5 µA




Promass F is a highly accurate device regardless of varying process conditions that is suited to a broad range of applications. Combined with the smallest transmitter housing available it delivers full performance on the smallest footprint. It is available with an extra-compact stainless steel hygienic housing and can be placed into the most compact rigs.

Benefits

  • Highest process safety – immune to fluctuating and harsh environments
  • Fewer process measuring points – multivariable measurement (flow, density, temperature)
  • Space-saving installation – no in/outlet run needs
  • Space-saving transmitter – full functionality on smallest footprint
  • Time-saving local operation without additional software and hardware – integrated web server
  • Integrated verification – Heartbeat Technology™

Applications

  • Measuring principle operates independently of physical fluid properties such as viscosity or density
  • Highest measurement performance for liquids and gases under varying, demanding process conditions

Device properties

  • Mass flow: measured error ±0,05% (PremiumCal)
  • Rated secondary containment up to 40 bar (580 psi)
  • Nominal diameter: DN 8 to 250 (3/8 to 10")
  • Robust, ultra-compact transmitter housing
  • High ingress protection: IP69K
  • Local display available


Promass F is a highly accurate device regardless of varying process conditions that is suited to a broad range of applications. Combined with the smallest transmitter housing available it delivers full performance on the smallest footprint. It is available with an extra-compact stainless steel hygienic housing and can be placed into the most compact rigs.

Benefits

  • Highest process safety – immune to fluctuating and harsh environments
  • Fewer process measuring points – multivariable measurement (flow, density, temperature)
  • Space-saving installation – no in/outlet run needs
  • Space-saving transmitter – full functionality on smallest footprint
  • Time-saving local operation without additional software and hardware – integrated web server
  • Integrated verification – Heartbeat Technology™

Applications

  • Measuring principle operates independently of physical fluid properties such as viscosity or density
  • Highest measurement performance for liquids and gases under varying, demanding process conditions

Device properties

  • Mass flow: measured error ±0,05% (PremiumCal)
  • Rated secondary containment up to 40 bar (580 psi)
  • Nominal diameter: DN 8 to 250 (3/8 to 10")
  • Robust, ultra-compact transmitter housing
  • High ingress protection: IP69K
  • Local display available





Downloads
  • Proline Promass F 100 Coriolis flowmeter
    Proline Promass F 100 Coriolis flowmeter
    110pp 2.9MB
    Download
